Vitalograph copd-6 Screener USB

4000_Lung_Monitor_USB_11

Fast & accurate COPD screener to identify those at risk of COPD at the pre-symptomatic stage.

The Vitalograph copd-6™ identifies those at risk of COPD at the pre-symptomatic stage.  Generates reports via USB connection and Vitalograph Reports software.  The device screens out those whose FEV1 is normal.

This allows early medical intervention and facilitates better clinical outcomes.

  • Monitors COPD patients using their obstructive index which is based on a percent of predicted.
  • Displays FEV1, FEV6, ratio and % predicted, obstructive index, COPD classification and lung age.
  • Screens out anyone with normal FEV1 without the risk of false COPD negatives.
  • Facilitates ‘case selection’ so that spirometry can be focused on those likely to be diagnosed with COPD.
  • Displays the GOLD COPD classification (stage I – IV) to help recognize the need for a change in the patient’s management plan.
  • Automatically sends data after each blow.
  • Can also send session data.
  • Large, easy-to-read display.



One of our 4000 Series of respiratory monitors and screeners, the COPD-6 USB comes with:



Product Code: 40451

Product Respiratory Monitor copd-6 USB
Model 4000
Dimensions 109mm (length) x 63mm (width) x 42mm (height)
Flow Detection Principal Stator rotor
Accuracy Better than ± 3%
Back Pressure Less than 0.15kPa/L/second @ 14L/s
Measurement Range 0 – 9.99 L BTPS
Power Supply 2 x AAA batteries
Battery Life 3 months of use, 3 tests per day
Quality Check Slow start of test (Vext>5%) or a cough detected in the first second
Performance Standards & Guidelines ATS/ERS 2019, ISO 23747:2015, ISO 26782:2009
Communications USB2.0/3.0
PC Requirements Windows® 7, Windows® 8 or Windows® 10
Auto power down time 2 minutes

  • 28501 Eco BVF (100)
  • 28572 Eco BVF + Disposable Noseclips (80)
  • 20242 SafeTway Mouthpieces (200)
  • 20303 Disposable Noseclips (200)
  • 20980 SafeTway Mouthpieces mini (50)
  • 20991 SafeTway Mouthpieces long (130)
  • 40167 Pouch Spare (x10)
  • 40079 USB Cable - 1M MINI-B to USB A
