Spacelabs HeartSave PAD Defibrillator

Spacelabs HeartSave PAD Defibrillator – for emergency first aid situations.  The HeartS­a­ve (AED/PAD) only de­li­vers an electric shock if life-threa­ten­ing fi­bril­la­ti­on is ac­tual­ly de­tec­ted.

Ea­sy-to-un­der­stand voice prompts guide the user through the res­cue pro­ce­du­re, thus eli­mi­na­ting the pos­si­bi­li­ty of the de­vice being ope­ra­ted in­cor­rect­ly.

Features includes:

• Voice Prompts
• Compact Flash Card
• 3 Year Lithium battery

Product: Spacelabs Primedic HeartSave PAD Defibrillator – for first aiders

Part No: 97432

• Defibrillation
  • Impulse shape: biphasic, current-controlled impulses, external (CCD)
  • Energy: 50 – 360 J according to patient impedance
  • Analysis time: 7 – 12 s
  • Asystole threshold < 200 μV
  • Artefact detection
  • Pacemaker detection
  • Pediatric Mode: Pediatric button or Savepads Mini
• ECG
  • Derivation: Einthoven II
  • Patient resistance: 23 – 200 Ohm
  • Heart rate: 30 – 300 per min.
• Defibrillation electrodes
  • Shelf life: 36 months
  • Cable length: according to the model between 1,3 m and 2,0 m
  • Active electrode surface: 174 cm² overall
• Data management
  • Removable memory: CompactFlash (CF) card 2GB
  • Data/voice recording: approx. 24 h data and voice recording
  • Read out software (CD): optional
• Power supply
  • Model: LiMn02
  • Voltage: 15 V
  • Capacity (nominal): 2 Ah
  • Service life: 3 years
  • Discharges/shocks 140@360J
  • Environmental conditions
  • Operating condition: 0°C … 55°C (30…95% rel. humidity without condensation, 700 … 1060 hPa)
  • Storage conditions: -20°C … +70°C (20…95% rel. humidity without condensation, 500 … 1060 hPa)
• Resuscitation guidelines
  • guidelines 2010 (ERC/AHA) at factory
• Protection Class
  •  IP55
• Dimensions
  • Height x Width x Depth 25 cm x 28 cm x 9 cm
  • Weight incl. power supply : approx. 2.5 kg
  • Standard Scope of Delivery :battery 3, 1 pair SavePads AED, 1 SaveCard

• Spacelabs,Primedic FirstAid min.pdf
